Tascam DR-40X Portable Four-Track Digital Audio Recorder and USB Audio Interface


The Tascam DR-40X Four Track Audio Recorder is a highly portable recording device ideal for DJS, musicians, sound designers, filmmakers, and field recordists

Out of stock
Availability: In Stock | Free UK Shipping

The Tascam DR-40X Four Track Audio Recorder is a highly portable recording device ideal for musicians, sound designers, filmmakers, and field recordists.

The DR-40X intuitive design makes it incredibly easy to use. Record, adjust levels, delete bad takes, add markers. All at the push of a button. And the ability to change between recording techniques (A-B and X-Y) is as easy flipping the microphone swivel. The dual XLR/TRS combo jacks support line and mic level. In addition to the dual condensers on top of the device, the DR-40X is a versatile, portable recording tool that is extremely effective regardless of context.

The DR-40X is extremely compact but does not skimp on sound quality. The pair of condenser microphones responds to SPL levels of 125db meaning it can get crisp recordings in almost any sonic environments. Capture every detail.


High-quality unidirectional stereo condenser microphones that can record in A-B and X-Y positions
XLR/TRS inputs compatible with +4dBu line level / +48V
4-channel mode that can be used for dual recording and nondestructive overdub recording, etc.
Support multiple languages for menu (ENG/FRA/DEU/ITA/ESP/RUS/PRT/JPN/CHI/KOR)
Overwrite function for Punch-In recording with one level of Undo
Functions as a 2in/ 2out USB Audio Interface for Mac, PC or iOS recording
Dictation mode designed for human voice recording and transcription
MS decoding function making it possible to use M-S microphones
Optional RC-3F foot switch and RC-10 wired remote control can be connected
Long-time operation of maximum 18 hours is possible using just the internal batteries
Reverb effect
Auto recording function
Proven high sound pressure design for capturing loud sounds of up to 125dB SPL
Peak reduction function that detects peaks and automatically sets the optimal level
Self timer recording function
Seamless gain control
Low-cut filter with three levels (40/80/120Hz)
Speed change (VSA) function for adjusting the speed from 0.5 to 1.5 times (in 0.1 increments)
Level align feature that prevents uneven volume levels
Equalizer setting for adjusting playback sound quality
Divide/delete functions
Loop/repeat playback function that is a convention for practising music and studying languages
Resume function that retains the last stop position and starts playback from that position when power is turned back ON
Jump-back playback function that skips back a preset number of seconds during playback
QUICK menu button for easy access to various functions
High-quality 24-bit/96kHz WAV/BWF linear PCM and MP3
SD/ SDHC/ SDXC (up to 128GB) can be used for recording media
Mark function that can set up to 99 points for a single track
Audio files created on computers can be played (Only in formats compatible with this product)
Built-in monaural speaker with an output of 0.3W
Pre-recording buffer that can record up to 2 seconds prior to starting recording
When a predetermined maximum file size is reached, a new file is created to continue recording
Track increment creates new files at arbitrary locations during recording
File name format can be set to use a user-defined word or the date
The first six characters of the file name for recording can be set freely
Playlist function
A chromatic tuner is equipped which is helpful for practising musical instruments
Stereo mini line output / Headphone output connector
128×64 pixel graphic LCD with backlight
High-speed file transfer to a computer using USB 2.0
Powered by 3 AA batteries, USB bus power, or optional AC adapter (PS-P520E)
Rubber feet for improving acoustic properties during desktop recordings are included
Tripod attachment screw-hole built into the unit

Recording Media: SD card (64MB to 2GB), SDHC card (4GB to 32GB), SDXC card (up to 12
File System: FAT16/32
Sampling Frequency: 44.1k / 48k / 96k Hz
Bit-depth: 16 / 24-bit
Sampling Frequency: 44.1k / 48k Hz
Recording Bit-rate: 32k / 64k / 96k / 128k / 192k / 256k / 320k bps
Playback Bit-rate: 32k to 320k bps, VBR, ID3TAG Ver. 2.4
Number of Channels: 4-channel (2 Stereo)
Playback speed control: 0.5 to 1.5 times (in 0.1 increments) * 44.1k/48kHz only
Built-in Microphone: Unidirectional, Stereo (switchable between A-B and X-Y positions)
Connector: XLR/TRS Combo jack (1: GND, 2: HOT, 3: COLD)
Nominal Input Level: –19dBV (MIC) / +4dBu (LINE)
Maximum Input Level: –3dBV (MIC) / +20dBu (LINE)
Input Impedance: 2.2kΩ (MIC) / 10kΩ (LINE)
Connector: 1/8" (3.5mm) Stereo Mini jack (Unbalanced) for LINE connection
Nominal Output Level: –14dBV (10kΩ load)
Maximum Output Level: +2dBV (10kΩ load)
Output Impedance: 12Ω
Maximum Output Power: 20mW + 20mW (32Ω load)
Connector: USB Micro B-type
Built-in Speaker: 0.3W, Mono
Low-cut Filter: 40 / 80 / 120Hz
Chromatic Tuner: C1 to B6, A4 = 435Hz to 445Hz (in 1Hz increments)
Effector: 6 presets (Hall 1, Hall 2, Room, Studio, Plate 1, Plate 2)
Tripod attachment screw-hole: 1/4" Tripod attachment screw-hole
Power: 3 AA Batteries, USB bus power, AC 100 to 240V (optional AC Adapter)
Power Consumption: 2.5 W (Max)
Alkaline (EVOLTA): approx. 18 hours (2ch WAV, 44.1kHz, 16-bit, using Built-in Microphone, JEITA)
Ni-MH (eneloop): approx. 16 hours (2ch WAV, 44.1kHz, 16-bit, using Built-in Microphone, JEITA)
Dimensions (W×H×D): 2.75" × 6.1" × 1.37" / 70 × 155 × 35 mm
Weight: 8.3 oz. / 213 g
